Part No |
90NR0JA1-M002N0 |
Sales Model Name |
GA605WV-AI-OLED9132G |
EAN Code |
4711387678022 |
UPC Code |
197105678026 |
WEEE |
2.586 |
BASE UNIT |
VSNR0JA1-BU1010 |
|
|
Marketing Name |
ROG Zephyrus G16 |
Operating System |
Windows 11 Home |
Office |
1-month trial for new Microsoft 365 customers. Credit card required. |
Color |
Eclipse Gray |
Dimension (W x D x H) |
35.4 x 24.6 x 1.49 ~ 1.64 cm (13.94" x 9.69" x 0.59" ~ 0.65") |
Weight |
1.85 Kg (4.08 lbs) |
Processor |
AMD Ryzen™ AI 9 HX 370 Processor 2.0GHz (36MB Cache, up to 5.1GHz, 12 cores, 24 Threads); AMD XDNA™ NPU up to 50TOPS |
Chipset |
N/A |
Intergrated GPU |
AMD Radeon™ Graphics |
Discrete/Optimus |
MUX Switch + NVIDIA® Advanced Optimus |
Graphic |
NVIDIA® GeForce RTX™ 4060 Laptop GPU (233 AI TOPs) |
Graphic Wattage |
ROG Boost: 1940MHz* at 100W (1890MHz Boost Clock+50MHz OC, 85W+15W Dynamic Boost) |
Graphic Memory |
8GB GDDR6 |
Neural Processor |
AMD XDNA™ NPU up to 50TOPS |
Panel Size |
16-inch |
Resolution |
2.5K (2560 x 1600, WQXGA) 16:10 aspect ratio |
Refresh Rate |
240Hz |
Response Time (G2G) |
0.2ms |
Viewing Angle |
89/89/89/89 |
Panel Tech |
OLED |
Brightness |
500 nits |
Contrast Ratio |
1,000,000:1 |
DCI-P3 % |
100% |
Glare |
Glossy display |
Adaptive-Sync technology |
G-Sync / Adaptive-Sync |
Pantone |
Pantone Validated |
Nebula Display |
ROG Nebula Display |
Support Dolby Vision HDR |
Yes |
On board memory |
16GB*2 LPDDR5X on board |
Total System Memory |
LPDDR5X 32GB |
Memory Slot |
N/A |
Memory Max. |
32GB |
Multi-channel memory technology |
Support dual channel memory |
Storage |
1TB PCIe® 4.0 NVMe™ M.2 SSD |
M.2 slots support either SATA or NVMe |
2 |
M.2 SSD Support List |
1TB M.2 NVMe PCIe 4.0 SSD
2TB M.2 NVMe PCIe 4.0 SSD |
Expansion Slot (includes used) |
2x M.2 PCIe |
LAN |
N/A |
Wireless |
Wi-Fi 7(802.11be) (Triple band) 2*2+Bluetooth® 5.4 Wireless Card (*Bluetooth® version may change with OS version different.) |
I/O Ports |
1x Type-C USB 4 with support for DisplayPort™ / power delivery (data speed up to 40Gbps) 1x USB 3.2 Gen 2 Type-C with support for DisplayPort™ / power delivery (data speed up to 10Gbps) 2x USB 3.2 Gen 2 Type-A (data speed up to 10Gbps) 1x card reader (SD Card) (SD Express 7.0) |
Display output |
1x HDMI 2.1 FRL |
Camera |
1080P FHD IR Camera for Windows Hello |
Mic |
Built-in 3-microphone array |
Keyboard Type |
Backlit Chiclet Keyboard 1-Zone RGB With Copilot key
*Copilot in Windows (in preview) is rolling out gradually within the latest update to Windows 11 in select global markets. Timing of availability varies by device and market. Learn more: https://www.microsoft.com/en-us/windows/copilot-ai-features?r=1#faq |
Aura Sync |
Yes |
Touchpad |
Touchpad N/A |
Speakers |
4-speaker (dual force woofer) system with Smart Amplifier Technology, 2 Tweeters |
Audio |
1x 3.5mm Combo Audio Jack Built-in 3-microphone array |
Audio Tech |
AI noise-canceling technology Dolby Atmos Hi-Res certification (for headphone) Smart Amp Technology |
Security |
BIOS Administrator Password and User Password Protection Pluton Security Processor Secured-core PC (Level 3) Trusted Platform Module (Firmware TPM) |
Antivirus |
McAfee® 30 days free trial |
Battery |
90WHrs, 4S1P, 4-cell Li-ion |
Fast charging |
Recharge from 0-50% in 30 minutes |
Power |
Rectangle Conn, 200W AC Adapter, Output: 20V DC, 10A, 200W, Input: 100-240V AC, 50/60Hz universal |
Xbox Game Pass |
Xbox Game Pass for PC_3 months (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass for PC. Eligible markets are determined at activation. Game catalog varies by region, device, and time.) |
Ecolabels & Compliances |
N/A |
Reparability Index (for France) |
?.? |
