| CAMERA |
|
| Image Sensor: |
1/2.7" Progressive Scan CMOS Sensor |
| Lens: |
Focal Length: 4.0 mm |
| |
Aperture: F1.6 |
| |
Field of View: 105.4° (Diagonal), 88.0°(Horizontal), 46°(Vertical) |
| Night Vision: |
Infrared Night Vision (52 ft / 16 m) |
| |
Color Night Vision (52 ft / 16 m) |
| Lighting |
2× Built-in Spotlights |
| Interface & Button: |
1× Power Button |
| |
1× RESET Button |
| |
1× microSD Card Slot (Up to 512 GB) |
| Pan/Tilt Range: |
Pan Mechanical Range: 340° (360° Pan Coverage) |
| |
Tilt Mechanical Range: 90° (141° Tilt Coverage) |
| SOLAR PANEL |
|
| Connection Capacity: |
A solar panel can only connect to one camera. |
| Output Port |
Type-C |
| VIDEO & AUDIO |
|
| Maximum Resolution: |
3K 5MP (2880 × 1620 px) |
| Frame Rate: |
15 fps |
| Digital Zoom |
13.5x |
| Live View: |
Yes |
| Video Compression |
H.264 |
| Image Enhancement: |
3DNR |
| |
WDR |
| Audio Input & Output: |
|
| Audio Communication: |
Built-in Microphone and Speaker |
| Siren Volume: |
Two-Way Audio with Noise Cancellation |
| |
78.9 dBA (Level measured at 10 cm distance) |
| STORAGE |
|
| Local Storage: |
microSD Card Slot on Camera (Up to 512 GB, microSD card not included) |
| Cloud Storage: |
Tapo Care Cloud Storage Services (Subscription required) |
| DETECTION and NOTIFICATIONS |
|
| Sensor: |
Motion Sensor |
| |
Ambient Light Sensors |
| AI Detection: |
Motion Detection |
| |
Person Detection |
| |
Pet Detection |
| |
Vehicle Detection |
| Activity Zones: |
Yes |
| Output Notification : |
System Notification |
| |
System Notification with Snapshot (Tapo Care Services) |
| NETWORK |
|
| Network Connectivity: |
Connect via Wi-Fi |
| Wireless Connectivity: |
IEEE 802.11b/g/n, 2.4 GHz Wi-Fi |
| SECURITY |
128-bit AES Encryption with SSL/TLS WPA/WPA2-PSK |
| POWER |
|
| Power Source: |
Built-in Rechargeable Lithium-ion Battery |
| |
5V DC Power Adapter (Not included) |
| |
Solar Panel: Tapo A201 |
| Input Voltage: |
5.0 V, 2.0 A |
| Output Voltage: |
/ |
| GENERAL |
|
| Smart Integration: |
Google Assistant, Amazon Alexa |
| Weather Resistance: |
IP65 for both camera and solar panel |
| Mounting Options: |
Eave-Mounted |
| |
Wall-Mounted |
| |
Pole-Mounted (Pole-Mounting required But Not Included) |
| System Requirements: |
Tapo App: iOS 12.0 or higher, Andriod 7.0 or higher |
| Operating Temperature: |
-20°C to 45°C (-4°F to 113°F) |
| Operating Humidity: |
10% ~ 90% RH, Non-condensing |
| Storage Humidity: |
0 ~ 90% RH, Non-condensing |
| Charging Temperature: |
0°C to 45°C (32°F to 113°F) |
| Dimensions ( W x D x H ): |
Camera Dimensions: 141 x 128 x 84 mm (5.55 x 5.04 x 3.31 in) |
| |
Solar Panel Dimensions: 173.4 x 120.4 x 15.7 mm (6.83 x 4.74 x 0.618 in) |
| Package Content: |
Tapo C630 Camera × 1 |
| |
Tapo A201 Solar Panel × 1 |
| |
Tapo A201 Solar Panel Bracket × 1 |
| |
Base Cover × 1 |
| |
Detachable Antenna × 1 |
| |
USB Adapter Cable × 1 |
| |
Extension Wire × 1 |
| |
Cable Zip Tie × 1 |
| |
Mounting Screws and Anchors |
| |
Mounting Template Stickers x 2 |
| |
Quick Start Guide |
| Certifications: |
CE, FCC, JRF, VCCI, RCM, NTRA, NCC, BSMI, DOE, CEC, IP65, RoHS |
