| CAMERA |
|
| Image Sensor: |
1/2.8" Progressive Scan CMOS Sensor |
| Lens: |
Focal Length: 4 mm |
| |
Aperture: F1.6 |
| |
Field of View: 100.6° (Diagonal), 84.4°(Horizontal), 44.3°(Vertical) |
| Night Vision: |
2× 850 nm IR LEDs (33 ft / 10 m |
| |
Full-Color Color Night Vision |
| Lighting |
2× Built-in Spotlights |
| Interface & Button: |
1× Power Button |
| |
1× RESET Button |
| |
1× microSD Card Slot (Up to 512 GB) |
| Pan/Tilt Range: |
Pan Mechanical Range: 340° (360° Pan Coverage) |
| |
Tilt Mechanical Range: 90° (130° Tilt Coverage) |
| SOLAR PANEL |
|
| Connection Capacity: |
A solar panel can only connect to one camera. |
| Output Port |
Type-C |
| VIDEO & AUDIO |
|
| Maximum Resolution: |
2K 3MP (2304 × 1296 px) |
| Frame Rate: |
15 fps |
| Digital Zoom |
10.8x |
| Live View: |
Yes |
| Image Enhancement: |
3DNR |
| |
WDR |
| Audio Input & Output: |
Built-in Microphone and Speaker |
| Audio Communication: |
Two-Way Audio with Noise Cancellation |
| Siren Volume: |
97.2 dBA (Level measured at 10 cm distance) |
| |
68.2 dBA (Level measured at 300 cm distance) |
| STORAGE |
|
| Local Storage: |
microSD Card Slot on Camera (Up to 512 GB, microSD card not included) |
| Cloud Storage: |
Tapo Care Cloud Storage Services (Subscription required) |
| DETECTION and NOTIFICATIONS |
|
| Sensor: |
Single Motion Sensor |
| AI Detection: |
Motion Detection |
| |
Person Detection |
| Activity Zones: |
Yes |
| Output Notification : |
System Notification |
| |
System Notification with Snapshot (Tapo Care Services) |
| NETWORK |
|
| Network Connectivity: |
Connect via Wi-Fi |
| Wireless Connectivity: |
IEEE 802.11 b/g/n/ax, 2.4 GHz |
| SECURITY |
|
| |
128-bit AES Encryption with SSL/TLS,AES |
| |
WPA/WPA2-PSK/WPA3 |
| POWER |
|
| Power Source: |
Built-in Rechargeable Lithium-ion Battery |
| |
Solar Panel: Tapo A201(included) |
| Input Voltage: |
Adapter Input: 100-240 V, 50/60 Hz
(Not include) |
| Output Voltage: |
Adapter Output: 5.0 V, 1.0 A (Not include) |
| |
Solar Panel Max Charging Voltage: 5.2 V |
| |
Solar Panel Max Charging Power: 2.5 W |
| GENERAL |
|
| Smart Integration: |
Google Assistant, Amazon Alexa |
| Weather Resistance: |
IP65 for both camera and solar panel |
| Mounting Options: |
Ceiling-Mounted |
| |
Wall-Mounted |
| |
Eave-Mounted |
| |
Pole-Mounted (Pole-Mounting loops required but not included) |
| System Requirements: |
Tapo App: iOS 12.0 or higher, Andriod 7.0 or higher |
| Operating Temperature: |
-20°C to 45°C (-4°F to 113°F) |
| Storage Temperature: |
-20°C to 60°C (-4°F to 140°F) |
| Operating Humidity: |
10% ~ 90% RH, Non-condensing |
| Storage Humidity: |
0 ~ 90% RH, Non-condensing |
| Charging Temperature: |
0°C to 45°C (32°F to 113°F) |
| Dimensions ( W x D x H ): |
Camera Dimensions: 130.88 × 116.09 × 84.06 mm (5.15 × 4.57 × 3.31 in.) |
| |
Solar Panel Dimensions: 173.4 x 120.4 x 15.7 mm (6.83 x 4.74 x 0.618 in.) |
| Package Content: |
Tapo C610 Camera × 1 |
| |
Tapo A201 Solar Panel × 1 |
| |
Tapo A201 Solar Panel Bracket × 1 |
| |
Base Cover × 1 |
| |
USB Adapter Cable × 1 |
| |
Extension Wire × 1 |
| |
Cable Zip Tie × 1 |
| |
Mounting Screws and Anchors |
| |
Mounting Template Stickers |
| |
Quick Start Guide |
| Certifications: |
CB, CE, FCC, DOE, CEC, RCM, KC, JFR,VCCI,NCC, BSMI, NTRA, IP65 |
